Kubernetes Operator

Intro

What is the Netmaker Kubernetes Operator?

The Netmaker Kubernetes Operator securely connects your Kubernetes cluster to a Netmaker WireGuard network.

It allows:

• Kubernetes workloads to talk to VMs, servers, and edge devices

• Netmaker devices to securely access Kubernetes services

• All traffic to stay private, encrypted, and zero-trust

No manual VPN setup. No complex routing.

Why Use the Netmaker Kubernetes Operator?

Modern infrastructure often spans multiple environments:

• Kubernetes clusters running containerised applications

• Virtual machines and bare-metal servers

• Edge devices and IoT deployments

• Hybrid cloud environments

Traditionally, connecting these different environments requires complex VPN configurations, firewall rules, and network routing. The Netmaker Kubernetes Operator simplifies this by:

• Eliminating Network Complexity: No need to manually configure VPNs or complex routing rules

• Enabling Secure Communication: All traffic flows through encrypted WireGuard tunnels

• Providing Native Kubernetes Integration: Use standard Kubernetes Services and annotations

• Supporting Bidirectional Access: Kubernetes workloads can reach Netmaker services, and Netmaker devices can reach Kubernetes services

What Can You Do With the Operator?

The operator provides three main capabilities:

• Egress Proxy: Access Netmaker services (APIs, databases, etc.) from your Kubernetes applications using standard Kubernetes Service names

• Ingress Proxy: Expose your Kubernetes services to devices on your Netmaker network

• API Proxy: Securely access your Kubernetes API server through Netmaker tunnels with RBAC support that syncs with the users on Netmaker controlplane

Key Concepts

Netmaker Network

A Netmaker network is a WireGuard-based virtual network that connects devices across different locations. Devices on the network can communicate securely using private IP addresses assigned by Netmaker.

Netclient

Netclient is the agent that runs on devices to connect them to a Netmaker network. The operator uses netclient as a sidecar container to provide WireGuard connectivity to Kubernetes pods.

Operator

A Kubernetes operator is a controller that extends Kubernetes functionality. This operator watches for specific Kubernetes resources (like Services with annotations) and automatically configures networking to connect them with Netmaker networks.

Cluster Egress vs Cluster Ingress

• Egress Proxy: Allows Kubernetes workloads to access services on the Netmaker network (Kubernetes → Netmaker)

• Ingress Proxy: Allows Netmaker devices to access services running in Kubernetes (Netmaker → Kubernetes)

🧩 Common Use Cases

• Cross-Environment Database Access: Connect your Kubernetes applications to databases running on servers in your Netmaker network, without exposing them to the public internet.

• Multi-Cluster Communication: Enable secure communication between workloads in different Kubernetes clusters through a shared Netmaker network.

• Edge-to-Cloud Connectivity: Connect edge devices and IoT devices in your Netmaker network to services running in your Kubernetes cluster.

• Secure API Access: Allow remote developers and systems to securely access your Kubernetes API server through WireGuard tunnels.

• Hybrid Cloud Networking: Unify networking across cloud and on-premises infrastructure through a single Netmaker network.

Getting Started

Prerequisites

1

Kubernetes Cluster

• Kubernetes v1.11.3 or later

• Access via kubectl

• Sufficient permissions to create namespaces, deployments, and services

2

Netmaker Pro Server

• Running and accessible

• At least one network is configured

• Admin access to generate tokens

3

Netmaker Network Token

• Generated from your Netmaker server

• Used to join the Kubernetes cluster to the network

• Keep this secure – you'll need it during installation

4

Helm

• Helm v3.0 or later (recommended installation method)

Installation

Add Helm Repository

Add Helm repo

helm repo add netmaker-k8s-ops https://downloads.netmaker.io/charts/
helm repo update

Install the Operator

Helm install

helm install netmaker-k8s-ops netmaker-k8s-ops/netmaker-k8s-ops \
  --namespace netmaker-k8s-ops-system \
  --create-namespace \
  --set image.repository=<your-registry>/netmaker-k8s-ops \
  --set image.tag=<tag> \
  --set netclient.token="YOUR_NETMAKER_TOKEN_HERE" \
  --set api.enabled=true \
  --set api.serverDomain="api.example.com" \
  --set api.token="your-api-token-here" \
  --set api.syncInterval="30"

Using a Kubernetes Secret for the netclient token is recommended for production. Secrets are read from the operator namespace (netmaker-k8s-ops-system) by default.

Using Kubernetes Secret for token (recommended)

Create token secret

# Create secret
kubectl create secret generic netclient-token \
  --from-literal=token="YOUR_NETMAKER_TOKEN_HERE" \
  --namespace netmaker-k8s-ops-system

Examples

Cluster Egress

Expose services that are external to your Kubernetes cluster but available in your Netmaker network, making them accessible to your Kubernetes workloads.

Use Case: Allow Kubernetes applications to access Netmaker services (APIs, databases, etc.) using standard Kubernetes Service names.

Cluster Egress Service example

apiVersion: v1
kind: Service
metadata:
  name: netmaker-api-egress
  namespace: default
  annotations:
    # Enable egress proxy functionality
    netmaker.io/egress: "enabled"
    # Option 1: Use Netmaker device IP address
    netmaker.io/egress-target-ip: "100.93.135.2"
    # Option 2: Use Netmaker device DNS name (uncomment to use DNS instead)
    # netmaker.io/egress-target-dns: "api.netmaker.internal"
    # Optional: Custom secret configuration for netclient token
    # Note: Secrets are always read from operator namespace (netmaker-k8s-ops-system) for security
    # netmaker.io/secret-name: "custom-netclient-token"      # Default: netclient-token
    # netmaker.io/secret-key: "token"                         # Default: token
spec:
  ports:
  - name: http
    port: 8082
    targetPort: 8082  # This is the port on the Netmaker device (standard Kubernetes way)
    protocol: TCP
  # Note: The selector is optional - the controller manages endpoints directly
  # But including it helps with Service discovery
  selector:
    app: netmaker-egress-proxy
    service-name: netmaker-api-egress
  type: ClusterIP

Cluster Ingress

Expose Kubernetes services to devices on your Netmaker network, allowing Netmaker devices to access Kubernetes workloads.

Use Case: Enable Netmaker network devices to access Kubernetes services (APIs, databases, web apps) using Netmaker IPs or DNS names.

Cluster Ingress Service example

# Example: Expose Kubernetes Service to Netmaker Network

# This Service creates an ingress proxy that allows Netmaker devices to access your K8s service

apiVersion: v1
kind: Service
metadata:
  name: my-api-ingress
  namespace: default
  annotations:
    # Enable ingress proxy functionality
    netmaker.io/ingress: "enabled"
    # Optional: Specify DNS name for this service on Netmaker network
    # netmaker.io/ingress-dns-name: "api.k8s.netmaker.internal"
    # Optional: Custom secret configuration for netclient token
    # Note: Secrets are always read from operator namespace (netmaker-k8s-ops-system) for security
    # netmaker.io/secret-name: "custom-netclient-token"      # Default: netclient-token
    # netmaker.io/secret-key: "token"                         # Default: token
spec:
  ports:
  - name: http
    port: 80
    targetPort: 8080  # Port your application listens on
    protocol: TCP
  selector:
    app: my-api  # Your application selector
  type: ClusterIP
